227kg x 711mm Locking Drawer Slides Heavy Duty Fridge runners 1422mm extension
Available in lengths 610mm – 2032mm
Load Capacity 227 Kg/Pair
Width 76mm
Zinc Plated
Full Extension
Side Mounted
Sizes Available:
610mm Closed – 1220mm Extended.
660mm Closed – 1320mm Extended.
711mm Closed – 1422mm Extended.
813mm Closed – 1623mm Extended.
864mm Closed – 1728mm Extended.
914mm Closed – 1828mm Extended.
965mm Closed – 1930mm Extended.
1067mm Closed – 2134mm Extended.
1117mm Closed – 2234mm Extended.
1150mm Closed – 2300mm Extended.
1219mm Closed – 2438mm Extended.
1250mm Closed – 2500mm Extended.
1321mm Closed – 2642mm Extended.
1422mm Closed – 2844mm Extended.
1524mm Closed – 3048mm Extended.
1626mm Closed – 3252mm Extended.
1727m Closed – 3454mm Extended.
2032mm Closed – 4064mm Extended.
Heavy Duty Drawer Slides:
Using double-row steel balls, stable and thickened 2.5mm steel plate, used for refitting cars, large cabinets, large drawers, multimedia equipment, etc.
These Draw Slides are great for any environment whether it be for work or leisure.
They are able to be used in a number of applications from camper trailers to vans and everything in between.
One of the main features of these Draw Slides is that it is a Lock In & Lock Out, which means that when it’s the closed position it is locked and won’t slide open.
The same goes when it is in the open position.
| Capacity | Width | Closed | Extended | ||
|---|---|---|---|---|---|
| Capacity | Width | Closed | Extended | ||
1. | 150kg | 53mm | 400mm | 800mm | Shop |
| 2. | 150kg | 53mm | 500mm | 1000mm | Shop |
| 3. | 150kg | 53mm | 600mm | 1200mm | Shop |
| 4. | 150kg | 53mm | 700mm | 1400mm | Shop |
| 5. | 150kg | 53mm | 800mm | 1600mm | Shop |
| 5. | 150kg | 53mm | 850mm | 1700mm | Shop |
| 5. | 150kg | 53mm | 900mm | 1800mm | Shop |
6. | 227kg | 76mm | 508mm | 1016mm | Shop |
| 6. | 227kg | 76mm | 559mm | 1118mm | Shop |
| 6. | 227kg | 76mm | 610mm | 1220mm | Shop |
| 7. | 227kg | 76mm | 660mm | 1320mm | Shop |
| 8. | 227kg | 76mm | 711mm | 1422mm | Shop |
| 9. | 227kg | 76mm | 813mm | 1623mm | Shop |
| 10. | 227kg | 76mm | 864mm | 1728mm | Shop |
| 11. | 227kg | 76mm | 914mm | 1828mm | Shop |
| 12. | 227kg | 76mm | 965mm | 1930mm | Shop |
| 13. | 227kg | 76mm | 1067mm | 2134mm | Shop |
| 14. | 227kg | 76mm | 1117mm | 2234mm | Shop |
| 15. | 227kg | 76mm | 1168mm | 2336mm | Shop |
| 16. | 227kg | 76mm | 1219mm | 2438mm | Shop |
| 17. | 227kg | 76mm | 1270mm | 2540mm | Shop |
| 18. | 227kg | 76mm | 1321mm | 2642mm | Shop |
| 19 | 227kg | 76mm | 1422mm | 2844mm | Shop |
| 20. | 227kg | 76mm | 1524mm | 3048mm | Shop |
| 20. | 227kg | 76mm | 1626mm | 3252mm | Shop |
| 20. | 227kg | 76mm | 1727mm | 3454mm | Shop |
| 20. | 227kg | 76mm | 1829mm | 3658mm | Shop |
| 20. | 227kg | 76mm | 2032mm | 4064mm | Shop |
Is the $158.00 for a pair of 227kg slides –
Yes, it is pair, each pair of Locking Drawer Slides includes both the left and right sides for easy installation. Let us know if you have any other questions, thank you.
